How to Configure DIGICOM ADSL Router for NTC ADSL

Configuring NTC Digicom ADSL Router, a guide by TechSansar

Configuring NTC Digicom ADSL Router, a guide by TechSansar

Digicom ADSL router is one of the most popular ADSL routers among NTC ADSL Users in Nepal. They have dedicated support service as well. Here are some tips to configure your DIGICOM ADSL Router with Nepal Telecom’s ADSL service.

If you incur any problem during set up, call Toll free phone number 16600166000 from 10 AM to 6 PM, or you can comment back on this post.

  1. Open Internet Explorer and then type 192.168.1.1 in the address bar.
  2. Put admin in both username & password.
  3. Setup page will open & click on Network & then click on WAN.
  4. Default Route Selection – Auto.
  5. Click on Select Current ATM VC Table.
  6. VPI-8
  7. VCI-81
  8. Encapsulation-LLC
  9. Channel Mode-PPPoE
  10. Enable NAPT
  11. Enable IGMP
  12. Type username & password (Provided by NTC).
  13. Type – Continuous
  14. Click on Modify.
  15. Again click on Select Current ATM VC Table.
  16. Click on Save in the bottom of the page (red color) if not Press on F11 & then click on Save.
  17. Now you are ready to browse the Internet.

How do I enable security key in my Digicom 104wt R adsl router?

Simply, go to Network options, on the left side you will see a vast number of choices. Go to authentication and work for the one which you want (we suggest you WPA )

Here is a video tutorial about setting ADSL Router for NTC’s ADSL and how to secure it – prepared by Team TechSansar.


Besides configure Digicom router, we have some other configurations as well like Configuring SMC’s router. Or you can request us to make a tutorial of configuration for the router you need.

To those Bloggers & Webmasters who copied/copy this tutorial, we request you to give atleast a credit link on your site. :)
  • http://researchguru.co.cc/ GURU

    but this did not work in ASUS netbook PC with USB cable.
    I mean it works fine with LAN cable but not with USB cable.

    Hope to c a reply soon…

    • http://techsansar.com TechSansar

      Your service provider might not have the same configuration settings as we have illustrated here. Steps shown below are specific to operators, please consult them or let us know about your operator details.

      # VPI-8
      # VCI-81
      # Encapsulation-LLC
      # Channel Mode-PPPoE

    • http://www.hi-tech.com.np ANil

      may the the netbook or pc doesn’t support the driver (software). you can write mail to support@hi-tech.com.np for Technical Support to send the driver through via mail.

  • Prasanna Pokharel

    how do we change the password for the wi fi signals to make the network a secured one?

    • http://www.hi-tech.com.np ANil

      First click on Network below Network there is LAN WAN WLAN. click on Wlan and then click on Security from that you can change your wilress password

  • nabin

    dear sir i need a etherner controller and network controller driver for my msi cr400 series notebook.can you help me plz.

  • sagar

    I tried to connect through ADSL on my toshiba laptop…when i entered 192.168.1.1 in address bar…it asked for user name and password………..i entered ADMIN in both…………but after that the router home page doesnt open…….This process works very well in my desktop computer…but doesnt work in my laptop………….i tried in opera, mozzila, internet expolrer…but no result……..What should i do????

  • sabin

    i m sabin, i took adsl service by ntc 2 months before n router is digicom with 4lan and wlan. in the inital period my internet speed was satisfactory, after 20-22 daya its going slow and slow, after 40-50 days web page can’t open and now a days messenger also can’t open. the router status is good mead setting is in good condition but internet is very slow, does router have any defect or ntc internet speed is really down. may i know this ans on my email (hnbhusal@gmail.com)

  • sabin

    i m sabin, i took adsl service by ntc 2 months before n router is digicom with 4lan and wlan. in the inital period my internet speed was satisfactory, after 20-22 daya its going slow and slow, after 40-50 days web page can’t open and now a days messenger also can’t open. the router status is good mead setting is in good condition but internet is very slow, does router have any defect or ntc internet speed is really down. may i know this ans on my email (hnbhusal@gmail.com)

    • Sakar

      check your pc of virus or spyware. May be they are the problem.

      • sabin

        this sabin, that is not problem of virus, the device of ntc from where our adsl and telephone line will mix that got problem and now they fix the problem, after that my internet is ok.

    • Sajan

      Excuse me bro but can you tell me how can I configure through digicom router
      I just took ADSL net . And could’nt configure the router.could you help me?

    • robin

      i m also having the same problem as sabin.. i also hv the same router n i hv been using it from 20..22 days n the net is getting slower n slower….my friends tplink’s speed is good but i dont know whats the problem with mine??? any solutions??

  • devendra

    I have purches 2 pcs of digicom(ddsl104wrt) adsl router. i have configure 1 adsl router as Nepal telecom provided the instruction but i want to configure another router by WiFi with the same internet which i have configured. have any body suggest me for this problem

    • Nikhil Bansal

      any problem please call 16600 166000, Toll Free : DIGICOM Help : 10 AM to 6 PM

      • http://techsansar.com Team TechSansar.com

        Thank you for replying and helping our visitors!

    • jARUs_Dude

      ok you can do that..its very simple..you can connect any internet cable to your second modem and configure it for wireless

  • Rfn_roshan

    yo setup garni system video clip ma vya jan sagilo hunto

  • Rfn_roshan

    yo setup garni system video clip ma vya jan sagilo hunto

  • KRP

    how do I enable security key in my digicom 104wt R adsl router

  • KRP

    how do I enable security key in my digicom 104wt R adsl router

  • Nikhil Bansal

    any problem please call 16600 166000, Toll Free : DIGICOM Help : 10 AM to 6 PM

    • http://techsansar.com Team TechSansar.com

      Thank you for replying and helping our visitors!

  • Charu_ghatani

    Modify  garne thauma Add garda hun6 ki hudaina ni? ani password kasari change garne rauter ko .

  • Charu_ghatani

    Modify  garne thauma Add garda hun6 ki hudaina ni? ani password kasari change garne rauter ko .

  • Arun

    Dear Friends,
    I am Arun from Kathmandu. I have Digicom 104wt R adsl router. I changed username and password in place of admin and admin. Now I forget the username and password. I will be very happy if anybody suggest any idea to recover or reset them. (apparajuli@yahoo.com)

    • http://techsansar.com Team TechSansar.com

      Dear Arun,  call Toll free phone number 16600166000
      from 10 AM to 6 PM.
      There is official Digicom support office in Kathmandu or you can also contact the shop where you purchased Digicom Router.

      One Tip: did you try to reset the Router to its original setting by pressing the reset button (at the back of it)

  • Arun

    Dear Friends,
    I am Arun from Kathmandu. I have Digicom 104wt R adsl router. I changed username and password in place of admin and admin. Now I forget the username and password. I will be very happy if anybody suggest any idea to recover or reset them. (apparajuli@yahoo.com)

  • Kathmandu73

    how to setup wireless ………..connection

  • Sanjay

    how can i set the password for the wifi in adsl 2/2+ wireless G router

  • Khanal_ananta

    i was using digicom modem having 4 wLAN N 1 WAN .BUT FROM YESTERDAY WAN IS NOT WORKING. HOW WILL IT WORK?

  • Vampireblood52

    hey can u tell me how to do port forwarding in digicom router

  • Kathmandu73

    how to change my adsl password……

  • http://www.facebook.com/prabin2010 Prabin Luitel

    have problem in configuring ADSL router….

  • Nisam

    3G Service has not been supplied to NT GSM prepaid user. 3G le revolutionize nagari kaha 4G ko kurra gareko?

    Network ko kurra garyo vane NTC and NCELL suck!!!

  • Khushuma

    hello!!!
    please do help me how put security password? coz i have no idea at all and my wireless has been access to lots of PC coz of that ma net is slow…please do write in detail from where to set security password.

  • Aman

    hi everyone..i need some help..my router works good with my laptop…but it is quiet slow with other handheld devices..can anyone suggest me some help?

  • Avinav

    i’ not sure that my router supports port forwarding. I use Digicom DDSL 104Wt. can u let me know how to enable it?

  • Sujandongol

    internet ko signal 2-5min ko laagi red signal dekhauchha(disconnect) ani feri auto connect…do anyone have this kind of problem.??…net majjale chalchha….k problem ho??? tauko dukhi sakyo..

  • Pawan

    My ADSL wireless is not running properly…can u plz help me out, how do i setup wireless with security code….

    Plz help me….

  • Dipesh

    I have got a digicom router but my internet speed is too slow.
    My router configuration is fine. But only the problem is in internet speed. Whereas my friend have a tp-link router and his internet speed is great.

  • jackelite

    how to do port forwarding on digicom router? can you please tell me!!!!!!!

    • TechSansar

      To do port forwarding in Digicom ADSL Router, browse the network tab and then look for connection settings. But why do you want to do port forwarding – NTC’s ADSL will show mad behavior on doing that (if that’s the case)?

  • sunil

    When I press 192.168.1.1 in the address bar it just says connect or stay offline, what shall i do??

    • http://techsansar.com Team TechSansar.com

      You should connect it, maybe you should try different browsers. This is means your connection with the ADSL modem is not constant.

  • Asdfghqwerty

    after performing all the steps as said my router is still not connected  to internet.i am sure that all steps are correct still the internet indicator is red.on troubleshooting it shows dns problem .i am using internet with my other tp link router.how to fix this problem with digicom router???

    • http://techsansar.com Team TechSansar.com

      We have tested, verified, and this method is working; as mentioned in the official Digicom router brochure; if you’re having difficulty please contact the toll free no. given in the post.

      * If internet indicator is STILL red (which) is one of the major problem with NTC, then you must wait for another 5 minute or so. NTC ADSL takes long time to connect and have frequent disconnects giving problem like yours; we have faced that; and sadly NTC guys do nothing about it.

  • Unknown

    after all the setting I am getting the message on the page as “internet doesn’t have a ppp connection” …help me out….

  • Assistance

    how to schedule time to disable internet connection? i want my kids not be able to use the internet at night, example form 10pm to 8 am!!!!!!!!!!!!!!! help!!!!

  • http://techsansar.com Team TechSansar.com

    We all know NTC ADSL has problems but they tend to be lazy to fix, check ur router, user credentials, if not call NTC.

  • sansa_rana

    hello there…  i have a Digicom router and the problem i’m having is, it’s settings keeps changing in every once in a month or a week, And i have to reconfigure all the settings of my router again. Is it just my router or other Digicom routers have the same problem too??? Is there any way to keep the setting permanently?? Please help people….

  • http://www.gulmiresunga.com/ Technology Blog

    at first i also got problem on installing digicom router..It took me around a week to install the digicom router…This posts helps us a lot.

    Thanks a lot for posting this infomative post.
    Technology Blog

  • Sagar

    i have a digicom roueter and my net speed is decreasing day by day. it just has been 1 month i set up my router. what should i do????

  • Sagar_acharya22

    i just set up my digicom router about a  month ago and y net speed is decreasing day 2 day.. what should i do????

  • Raj

    i have got a digicom router i used asl for a long time but when i used it power link wan give to indecator but ethernet indicator not giving single so that i am very tried how to solve it

  • http://techsansar.com Team TechSansar.com

    The yellow signal gives that the device driver has not been installed correctly, so please ensure that you have the drivers ready. Two ways you can do it – install driver on the fly with internet connection OR download driver from the website, extract it and install from there.

  • preety

    i do have dual boot in my laptop…linux and window7…i can access internet from both ethernet and usb while using linux but the problem is when i use windows7 i cannot access internet through usb only ethernet works.How can i make my usb work in windows7 too????
    windows7 doesnt even detect the usb and the router model is DDSL 101Rt

  • Jimmy Page

    I’m currently using volume based adsl and I can’t log on to customer care on my Digicom 104W router. Is there any settings or such i need to change to be able to do so?

  • Snesh

    How to do port forwarding in Digicom router ? Please Reply :)

  • rojina

    i am unable to acces my router.. whever i try admin admin in my id and paswrod it says wrong pasword try again anad it is nt working even if i reset it

    • Chandan Mishra

      You have changed password of your router so it says Id and pass wrong.

  • Chandan Mishra

    how to configure the wi-fi settings in adsl?
